2024–2026 Ford Ranger key fob battery
The 2024–2026 Ford Ranger key fob takes a CR2032, a 20 × 3.2 mm 3 V lithium cell. This generation has 2 key types, so check which one you have below. Below: how to open it, what to do if it dies, and the manual we checked.
Buy CR2032 batteries CR2032 specs & equivalents
Our pick: Duracell CR2032, 2-pack on Amazon, a name-brand cell in child-resistant packaging.
Tip: change the spare key at the same time. Both cells usually age together.
Quick facts
Which key do I have?
| Key type | Version | Battery | Qty |
|---|---|---|---|
| Flip key | Flip key (turn-key start) | CR2032 | 1 |
| Smart key (push-button start) | Push-button start | CR2450 | 1 |
Confirmed in the 2024, 2025 and 2026 Ranger owner's manuals (CR2032 for the flip key).
Not sure? Open the fob and read the code printed on the old battery. It is always the safest check.
Before you start
- Get a new CR2032 or CR2450 cell from a fresh pack.
- Work over a table or soft cloth so small parts and buttons don’t get lost.
- Note which way the old battery faces before you take it out.
- Keep loose coin cells away from children and pets. See coin battery safety.
How to replace the 2024–2026 Ford Ranger key fob battery (flip key, Flip key (turn-key start))
- Press the button to fold out the key blade
- Use a small screwdriver to press the clip and release the battery cover, then lift the cover off
- Lever the old cell out gently, keeping clear of the circuit board
- Fit the new CR2032 with the + side facing up
- Clip the cover back on and test the buttons
How to replace the 2024–2026 Ford Ranger key fob battery (smart key, Push-button start)
- Press the release button and pull out the metal key blade
- Behind where the blade sat, twist a thin coin under the hidden tab to lift off the battery cover
- Ease the old cell out with a small screwdriver, keeping clear of the circuit board
- Fit the new CR2450 with the + side facing up
- Clip the cover back on, slide the key blade in and test the buttons
Confirmed in the 2024, 2025 and 2026 Ranger owner's manuals (CR2450 for push-button start keys). 2019-2023 online manuals have no key battery section, so not included.
After you change the battery
- Press lock and unlock from a few metres away. The car should react on the first press.
- On push-button start cars, start the engine once with the fob in your pocket.
- If nothing happens, re-open the fob and check the battery direction and contacts. More fixes: key fob not working after a battery change.
About the CR2032 battery
CR2032 is a 20 mm × 3.2 mm, 3 V lithium cell with a typical capacity of about 225 mAh. The same size is sold as DL2032, ECR2032, KCR2032, 5004LC. A CR2012 or CR2016 or CR2025 has the same diameter but is thinner, so it can fit loosely and runs down sooner. Stick with CR2032.
About the CR2450 battery
CR2450 is a 24.5 mm × 5 mm, 3 V lithium cell with a typical capacity of about 620 mAh. The same size is sold as DL2450, ECR2450, 5029LC.
Photos from Ford Ranger owners
No owner photos yet for this generation.
Other vehicles that use a CR2032
2021–2024 Ford Escape2017 Ford Focus2022–2026 Ford Maverick2024–2025 Hyundai Elantra2021–2023 Hyundai Elantra2022–2023 Hyundai Kona2020–2022 Hyundai Palisade2021–2023 Hyundai Santa Fe2021–2023 Hyundai Sonata2022–2024 Hyundai Tucson2021 Mazda CX-32024–2026 Mazda CX-30
Questions
What battery does the 2024–2026 Ford Ranger key fob use?
Flip key (turn-key start): 1 × CR2032 (flip key); Push-button start: 1 × CR2450 (smart key).
How many batteries does the 2024–2026 Ford Ranger key fob need?
Flip key (turn-key start): 1; Push-button start: 1.
Can I use a CR2012 or CR2016 or CR2025 instead of a CR2032?
It has the same 20 mm diameter but is thinner, so it can lose contact and runs down sooner. Use a CR2032.
Which battery names are the same as CR2032?
DL2032, ECR2032, KCR2032, 5004LC are the same size as CR2032.
Do I need to reprogram the key after changing the battery?
Most key fobs keep their pairing when the battery is changed. If the fob stops working, check the battery direction and contacts first; our troubleshooting guide covers the rest.
